GETAC E105M
MILITARIZED TABLET COMPUTER
The E105M is a highly rugged field tablet computer with an ultra bright 800 nit 8.4" SVGA display and the latest Intel A110 CPU. With its drop resistant magnesium case, the E105M includes 802.11b/g wireless LAN and Bluetooth 2.0 connectivity as standard features; EV-DO or GPRS/EDGE networks and integrated GPS available as options. Gigabit Ethernet and USB 2 connectivity is provided along with PCMCIA and a Smart Card Reader in a 3 lb. package. Dual batteries allow all-day operation in -20C to 60C temperatures with rain and blowing sand.
Data Sheet

GETAC V105M MILITARIZED CONVERTIBLE NOTEBOOK/TABLET COMPUTER
The V105M Convertible features either a 10.4" XGA or 12.1" WXGA LCD screen. The lightweight 5 lb. design and 180° rotatable display allows instant transformation from notebook to tablet PC. Its sealed magnesium alloy case employs fan-less conduction cooling to survive the harshest environments and the hard drive is dynamically protected to prevent damage if dropped when running. All ports and doors along with the keyboard are water-proof to protect the computer from fine dust and blowing rain per MIL-STD-810. Resistive touch or digitizer screens are available.
Data Sheet

RPC RUGGED 5 SLOT
ADD-IN COMPUTER
The RPC platform is designed for customization. It hosts long PCI & PCIe cards or 3U cPCI and PXI modules along with customer specific function modules such as encryption devices, receivers and decoders. Interfaces can terminate in MILSPEC connectors or custom patch panels. Select from AC or AC/DC/UPS power supplies with standard or MILSPEC connectors. Add a pre-heater to allow cold start operation from -40C. The RPC allows you to create a field portable system without having to start from scratch.
Data Sheet

RPC RUGGED 8 SLOT COMPACT
PCI ADD-IN COMPUTER
Build cPCI applications to take into field environments with the rugged RPC cPCI portable system. Equip it with any 3U cPCI SBC or even dual SBCs and your ready to host cPCI applications in the 8 slot backplane. The AC/DC/UPS power supply works anywhere and provides up to 30 minute operating time while relocating operating environments. Specify pre-heaters for cold working environments and the waterproof keyboard for messy ones. The highly rugged, precision welded chassis withstands the rigors of day to day deployed use.
Data Sheet

RPC PXI RUGGED 7 SLOT
PXI ADD-IN COMPUTER
Take PXI instrumentation applications to the field with the rugged RPC PXI portable system. Equip it with a National Instruments or AD Link Technology CPU and your ready to host PXI applications in the 7, 3U add-in slots. The AC/DC/UPS power supply works anywhere and provides up to 30 minute operating time while relocating operating environments. Specify pre-heaters for cold working environments and the waterproof keyboard for messy ones. The rugged welded chassis protects the system from the abuse of field environments.
Data Sheet

RPC MIL RUGGED 6 SLOT
MILSPEC ADD-IN COMPUTER
Get full MILSPEC from a COTS product. The off-the-shelf RPC-MIL is designed and certified to MILSPEC environmental and emissions requirements. It is a fully sealed, conduction cooled rugged add-in computer with 5 PCI and 1 PCI/ISA available slots. Wide range AC or DC power inputs plus a 30 minute internal UPS make it a natural for deployed operations, especially in harsh, dusty, wet and cold or hot conditions. MIL D38999 I/O connectors are available and the color, nameplates and control nomenclature is customer specifiable.
Data Sheet

RDU HB1200
OUTDOOR SUNLIGHT READABLE DISPLAY
The RDU provides full sunlight readability with 1200 nit luminance and a wide range of universal inputs. It is designed for extended outdoors operation in full direct sunlight while providing very high contrast in adverse viewing conditions. he 17" SXGA DBEF-enhanced TFT screen displays high speed video images without smearing or ghosting. Full 100:1 dimming range can be digitally controlled or via a continuously variable brightness knob. Manual display controls are available via pushbutton or remote IR controls and RS232 computer control is available.
Data Sheet

TETRASMART 2720A SERIES
PORTABLE INSTRUMENT CONTROLLERS
Take the ultra-slim Logic TetraSmart 2720As anywhere. These rugged attaché-style portable instrument controllers handle remote environments with a low-power Pentium M and an internal UPS. Control with the integral GPIB controller or host your dedicated hardware in one or two full-length PCI slots that lets you take your applications to the field. Operating and transport shock and vibration is handled with a welded stress-relieved aluminum case. Run up to 1.5 hours on the internal battery or plug into any AC or DC source from 90 to 265 VAC and 9 to 36 VDC.
Data Sheet

RMDDU RACK MOUNT DUAL DISPLAY UNIT
The RMDDU offers the highest resolution of any rack mounted display system. It employs two 16:10 format WUXGA 1920x1200 LCD displays in a 2U rack mount package 26" deep. The displays fold together and close into the drawer for slide in storage. Two independent video controllers provide universal inputs of: analog VGA, DVI, RS170 video, NTSC, PAL/SECAM (Interlaced), Composite Video, S-video, RGB Video, SD & HD Component Video (YCrCb). Independent front panel OSDs are provided along with USB feed-through connections.
Data Sheet

2722A MODULAR INSTRUMENT CONTROLLER
The 2722A is a self-contained 4U height 19" Instrument Controller with an internal 8-inch high brightness (400 cd/m²) LCD display. All the 2722A I/O ports are placed on the front panel for easy access and maintenance. The 2722A power and peripheral controls can be locked from the outside to prevent unauthorized users from operating the unit. Three open instrument interface slots are available for ISA or PCI plug-in modules. The unit can be rack mounted or used on the bench and has in integral pull out keyboard with touch pad pointing device.
Data Sheet
